Tonewinner digital Wi-Fi multimedia player factory

TY-i30 is a multimedia CD player.It plays songs push from Mobile phone, IPAD or laptop by DLNA or BT. As a top 10 audio brand in China, Tonewinner has 30+ years experience in designing and manufacturing acoustic products. As an original supplier, Tonewinner always warmly welcomes distributors, partners and customers around the world.

  • Model

    TY-I30
  • G.W.

    5.5KG

TY-i30 Hi-Fi Wireless Digital Media Player

Abundant Connections

It supports optical, coaxial digital inputs and outputs to connect to digital devices including amplifiers and CD players. It supports SD card and USB disk for lossless transmission. The built-in 4.1 Bluetooth module enables it to playback the audio of mobile phones, iPads and PCs via Bluetooth. It also supports Wi-Fi connection and small area network connection for wider range of music.

Hi-Fi and Lossless Sound

It can read and recognize several digital signals

and supports 192kHz output to reduce audio coloration

and bring more analytical sound.

Dolby Atmos AV Receiver

192kHz Digital Audio Receiver

The CS8416 form Cirrus Logic company supports sample rates up to 192 kHz.

It has an extremely low-jitter clock-recovery mechanism

that yields a very clean recovered clock from the incoming audio stream.

AD1955 Decoding Chip

AD1955 stereo digital audio playback system from Analog Devices company supports 24-Bit, 192 kHz sample rate PCM audio data, -110 dB THD and 120 dB SNR(not muted) at 48 kHz sample rate (A-Weighted stereo) and 123 dB SNR (mono).

OPA2134 Operational Amplifier

The OPA2134 Op-amp from Burr Brown is ultra-low distortion,

low-noise operational amplifiers with high output drive capability,

excellent DC performance and a wide output swing fully specified for audio applications.

Support Multiple Formats

Digital Lossless Transmission

It supports optical, coaxial digital inputs and outputs to digital devices including

amplifiers and CD players, which is more lossless.

USB Disk/ TF Card Playback

Dolby Atmos AV Receiver

Built Your Own Music Center

4.1 Bluetooth Wireless Transmission

Wi-Fi Wireless Connection

Connections

Compatible with IOS & Android Systems

Low Power Consumption

8W power consumption and 0.5W standby consumption is going to

give you more green and high efficient performance.





Dolby Atmos AV Receiver



Parameters
TY-i30
Size
444x103x294mm
SNR
≥102dB(A weight)
Material
Aluminum alloy
Frequency range
20Hz~65KHz(+1/-3dB)
Supported music formats
WAV,flac,APE,MP3,WMA
N.W
4.8KG
Reference Output Level
2Vrms±1.5dB(1KHz)







Overview of TY-i30 Digital Media Player

1. External Design

TY-i30 has silver aluminum alloy front panel and polished buttons, collaborating with the colorful display screen and smooth corners. Schematic display screen brings easy-adjustment and good looking.

2. Internal Design

It adopts CS8416 digital audio receiver supporting 192kHz/24Bit, AD1955 decoding chip supporting 120dB SNR and OPA2134 Hi-Fi operational amplifier.

3. Main Features

Outputs: 1 way balance, 2 way unbalance, 1 way optical and 1 way coaxial.

Inputs: Wi-Fi, Bluetooth, 1 way optical, 1 way coaxial, TF card and USB disk.

Connect to devices: Mobile phone, iPad, laptop, desktop, CD player, amplifier and other media devices.

Support Wi-Fi connection: Hotspot connection and local small area network connection for longer transmission.
