Tonewinner custom 2.0 1000W mono powerful home movie amplifier

AD-2500 is a 2×500W Hi-Fi amplifier for home theater system in the need of high pressure, large dynamic range and high transmission rate. Differential circuits and high power for stunning sound effect. As a top 10 audio brand in China, Tonewinner has 30+ years experience in designing and manufacturing acoustic products. As an original supplier, Tonewinner always warmly welcomes distributors, partners and customers around the world.

  • Model

    AD-2500
  • Channels

    2
  • Power

    2*560W
  • G.W.

    26KG



















Hi-Fi Circuit Design Dual Channels Power AV Amplifier





Build your high quality home theater

Multi-protection

Five protection design to ensure amplifier & speakers working steadily

560W high power output ensures strong driving

for multi-layer rich sound

Hi-Fi circuit design

It adopts balanced & unbalanced inputs, differential input & differential amplifying and constant current source, with temperature compensation circuit and multi-protection design, all of which make it more suitable for home theater system in the need of high pressure, large dynamic range and fast transmission.

Differential circuit

It adopts differential circuit to improve dynamic range and reduce supply noise & supply bounce

Customized filter capacitor

A total of 8 capacitors with 80000µF capacitance give more power and reduce harmonics in filtering solutions for powerful sound

High power transistor

8 pairs high power transistor NJW0281G/NJW0302G













* 8 pairs of NJW0281G/NJW0302G transistors from Onsemi company still work well when the current changes a lot so as to reduce impact on sound quality.

These hi-power transistors perform well in all frequency range to provide rich, analytical and pleasing sound, which constitute popular choices of audiophiles, audio engineers and tuners.

1200W large toroidal transformer, high power but low noise

Every detail matters

The cabinet is all black aluminum with acrylic board on the front. The pointer voltmeter is bright lake-blue, indicating its beauty and elegance














Parameters









Rated output power: 930W Rms/4Ω (THD=3%, single channel, 1KHz),

                                  560W Rms/8Ω (THD=1%, single channel, 1KHz),

                                 500W Rms/8Ω (THD=1%, dual channels, 1KHz),

 Rated impedance: 8 ohm

Gain: ≥29dB

THD: ≤0.01%

SNR: ≥110dB (A-weighted, analog pass-through)

Frequency range: 10Hz-50KHz (+1/-3 dB, analog through)

Minimum Power EMF:2V

N.W: 23.5kg, G.W: 26kg

Power supply voltage: ~110(60Hz)/~220V(50Hz)

Overall size: 440x 178x 420mm (WxDxH)








Dolby Atmos AV Receiver





Parameters
AD-2500
Power Output

930W RMS(8Ω per channels,1kHz,THD=3%)

560W RMS(8Ω per channels,1kHz THD=1%)

Frequency Response
10Hz-50KHz(+1/-3dB)
Whole Unit Gain
≥29dB
THD
≤0.01%
Size
440x178x420mm
Rated Impedance
8ohm
SNR
>110dB(A weight)
Channel
2
N.W
23.5KG
EMF
2V
Power Consumption
≥1100W
Warranty
1year
Accessories
instructions,wire,cetificate



AD-2500 adopts Hi-Fi design and it's an AV power amplifier professional amp, it has dual channels and each channels has 500 watts output power. And it's the hot sale 4K HD home theatre system amplifier. If you want to build a stereo surround sound cinema system, you can choose it.



Function of 2 channels AV amp



  • 2x560W dual-channel high-power output, infinite thrust.
  • Using differential amplifier circuit, strong driving force, small harmonic distortion, very strong.
  • Adopt five protections of overvoltage, overheating, overload, overcurrent and short circuit to ensure the safety of the body.
  • High-fidelity HIFI circuit, fully balanced output.
  • ON Semiconductor NJW0302G/NJW0281G audio dedicated high-power tube has a strong performance in large dynamic output.
  • 1200W giant ring cow, with low noise and high power.
